GP Series

GP50

6-axis, compact and high speed handling robots

Overview

The flexible MOTOMAN GP50 handling robot provides a payload of 50 kg and a maximum reach of 2,061 mm.

It is also available with protection class IP65/67 to operate in harsh environments.



Technical Details

  • Number of Axes
  • 6
  • Payload
  • 50 kg
  • Max. Working Range
  • 2,061 mm
  • Repeatability
  • 0.07 mm
  • Weight
  • 570 kg
  • Power Supply
  • 4 kVA
  • S Axis
  • 180 °/sec
  • L Axis
  • 187 °/sec
  • U Axis
  • 187 °/sec
  • R Axis
  • 250 °/sec
  • B Axis
  • 250 °/sec
  • T Axis
  • 360 °/sec
  • Mounting Options
  • Ceiling, Wall, Floor
